4.433619MHz Crystal C49U
4.433619MHz Crystal C49U

CAT. No. RQ5284

4.433619MHz Crystal C49U
product image thumb

4.433619MHz Crystal C49U

$4.5
Fixed frequency quartz crystal for ultra stable oscillation and RF use. - 4.433619MHz

Please call (02) 4782 6943

Description

Fixed frequency quartz crystal for ultra stable oscillation and RF use.

Specifications:
Frequency: 4.433619MHz
Frequency Tolerance: ±30Hz per 1MHz.
Operating Temperature: -20 to +70ºC.
Load Capacitance: 30pF (typical)


    Specifications

    Packaged Dimensions

    Packaged Length
    		 1cm
    Packaged Width
    		 0.3cm
    Packaged Weight
    		 0.001kg
    Packaged Volume
    		 0.0012l
    Packaged Height
    		 4cm

    Downloads

    RQ5284-dataSheetMain.pdf
