5K Spectrol 25 Turn Trimpot
5K Spectrol 25 Turn Trimpot

CAT. No. RT4648

5K Spectrol 25 Turn Trimpot
product image thumb

5K Spectrol 25 Turn Trimpot

$2.95
These are 25 turn industrial quality sealed trimpots. Pins are in a row, with 2.5mm spacing.Adjustment is vertical. Power rating is 0.5 watts.Value 5K...

Please call (02) 4782 6943

Description

These are 25 turn industrial quality sealed trimpots.
Pins are in a row, with 2.5mm spacing.
Adjustment is vertical.
Power rating is 0.5 watts.
Value 5K

    Specifications

    Packaged Dimensions

    Packaged Length
    		 0.5cm
    Packaged Width
    		 1cm
    Packaged Weight
    		 0.002kg
    Packaged Volume
    		 0.001l
    Packaged Height
    		 1.5cm

    Trimmer Potentiometer

    Trimpot Scredriver Slot
    		 Flat
    Trimpot Turns
    		 25 units
    Trim Pot Type
    		 Multi-turn vertical adjustment

    Passive Component

    Component package
    		 Square pack
    Passive mount type
    		 Through Hole
    Passive connector type
    		 Solder Legs
    Pack Quantity
    		 1pc
    Passive number of legs
    		 3 count
    Passive marking code
    		 Number code

    Resistance Rating

    Resistance level
    		 5k?

    Power Rating

    Continuous Power
    		 0.5W

    Product Availability

    Availability
    		 Stocked item

    Downloads

      Articles
      Articles

    RT4648-dataSheetMain.pdf
