SPST PCB Mount Tactile - Vertical & Horizontal with LED - Vertical Red
SPST PCB Mount Tactile - Vertical & Horizontal with LED - Vertical Red

CAT. No. SP0612

SPST PCB Mount Tactile - Vertical & Horizontal with LED - Vertical Red
product image thumb

SPST PCB Mount Tactile - Vertical & Horizontal with LED - Vertical Red

$4.45
Rating: 12VDC 50mAOperating Temperature: -50 ~ 70 degrees CContact Resistance: 100mOhm Max.Insulation Resistance: 100MOhm min at 100VDCWithstand Volta...

Please call (02) 4782 6943

Description

LED SPST PCB tactile switch
LED Power Supply: 3.5-4V DC @ 25mA

Orientation Colour Cat #
Vertical Red SP-0612
Vertical Green SP-0613
Vertical Blue SP-0614
Horizontal Red SP-0615
Horizontal Green SP-0616
Horizontal Blue SP-0617

    Specifications

    Electromechanical Switch

    Switch Function
    		 Single Action Momentary
    Pole Throw Type
    		 SPST
    Dielectric Strength
    		 100V
    Switch Connection
    		 PCB Pins
    Switch Type
    		 Tactile Pushbutton
    Poles / Contacts
    		 1 pole
    Throws / Positions
    		 1pos
    Switch Colour Coded
    		 Red
    Contact Resistance
    		 100m?
    Insulation Resistance
    		 100M?
    Mechanism Material
    		 Plastic

    Product Mounting

    Pin Spacing Depth
    		 2.5mm
    Pin Spacing Width
    		 5mm
    Mounting Method
    		 PCB

    DC Voltage Rating

    DC Voltage
    		 12V

    DC Current Rating

    DC current rating
    		 50mA

    Product Dimensions

    Length
    		 7.5mm
    Height
    		 17.3mm
    Width
    		 7.5mm

    Packaged Dimensions

    Packaged Length
    		 0.5cm
    Packaged Width
    		 0.5cm
    Packaged Weight
    		 0.001kg
    Packaged Volume
    		 0l
    Packaged Height
    		 2cm

    Product Availability

    Availability
    		 Stocked item

    Downloads

    SP0612-dataSheetMain.pdf
