Screw Terminal 30A Blade Fuse Holder
Screw Terminal 30A Blade Fuse Holder

CAT. No. SZ2044

Screw Terminal 30A Blade Fuse Holder
product image thumb

Screw Terminal 30A Blade Fuse Holder

$10.25
A standard duty low voltage in-line fuse housing to Suit standard blade style fuses rated up to 30 amps.

Please call (02) 4782 6943

Description

Screw terminal blade fuse holder. Easy install, just cut loop and connect to your circuit wiring.

Features:
• Low voltage DC only
• Easy installation without crimp or solder

    Specifications

    Product Dimensions

    Length
    		 35mm
    Width
    		 32mm
    Depth
    		 6mm

    Packaged Dimensions

    Packaged Length
    		 11.4cm
    Packaged Width
    		 8.5cm
    Packaged Weight
    		 0.022kg
    Packaged Volume
    		 0.15504l
    Packaged Height
    		 1.6cm

    Fuse

    Fuse Type
    		 blade

    DC Voltage Rating

    DC Voltage
    		 32V

    DC Current Rating

    DC current rating
    		 30A

    Fuse Holder

    Mounting
    		 Line
    Connection
    		 Screw Terminals
    Number of Fuse Slots
    		 1pc

    Product Availability

    Availability
    		 Stocked item
