Red 5mm LED 1200mcd Round Clear
Red 5mm LED 1200mcd Round Clear

CAT. No. ZD0152

Red 5mm LED 1200mcd Round Clear
product image thumb

Red 5mm LED 1200mcd Round Clear

$0.85
Red 5mm light emitting diode at 1200mCd brightness in Round Clear

Please call (02) 4782 6943

Description

LED

Red 5mm LED 1200mCd Round Clear

    Specifications

    Product Dimensions

    Diameter
    		 5mm

    Packaged Dimensions

    Packaged Length
    		 0.5cm
    Packaged Width
    		 0.5cm
    Packaged Weight
    		 0.002kg
    Packaged Volume
    		 0.001l
    Packaged Height
    		 3.5cm

    LED Components

    Light Colour
    		 Red
    Lens Type
    		 waterclear
    Light Wavelength
    		 660nm
    Viewing Angle
    		 15°
    Intensity
    		 1200mcd
    I<sub>f (typ)</sub> - Typical Forward Current
    		 20mA
    V<sub>f (typ)</sub> - Typical Forward Voltage
    		 1.7V
    Resistor for 12VDC
    		 510?
    Resistor for 9VDC
    		 360?
    Illumination Type
    		 Single Colour
    I<sub>f (max)</sub> - Maximum Forward Current
    		 30mA
    LED Type
    		 5mm Standard LED
    Resistor for 5VDC
    		 160?

    Product Availability

    Availability
    		 Stocked item
